Culligan MEDALLIST SERIES Service Manual

Specications
SPECIFICATIONS 3
CULLIGAN MEDALLIST SERIES WATER CONDITIONER WITH TIMECLOCK OR SOFT MINDER METER
8" MODEL 30
3
MODEL 45
3
MODEL
Control Valve Type 5-cycle Reinforced 5-cycle Reinforced 5-cycle Reinforced
Thermoplastic Thermoplastic Thermoplastic
Overall Conditioner Height 51 in 49 in 63 in
1,295 mm 1,245 mm 1,600 mm
Media Tank Dimensions (Dia. x Ht.) 8 x 44 in 10 x 40 in 10 x 54 in
203 x 1,118 mm 254 x 1,016 mm 254 x 1,372 mm
Salt Storage Tank Dimensions 16 x 43 in 18 x 43 in 18 x 43 in
(Dia. x Ht.) 457 x 1,092 mm 457 x 1,092 mm 457 x 1,092 mm
18 x 43 in
457 x 1,092 mm
Exchange Media, Type and Quantity Cullex
®
Media, 0.7 ft
3
Cullex Media, 1.0ft
3
Cullex Media, 1.5 ft
3
Underbedding, Type and Quantity Cullsan
®
Underbedding, Cullsan Underbedding, Cullsan Underbedding,
6 lb. 8 lb. 8 lb.
Exchange Capacity 18,300 gr @ 4 lb 20,200 gr @ 5.0 lb 24,900 gr @ 6 lb
@ Salt Dosage Per Recharge
1
25,100 gr @ 9.0 lb 29,400 gr @11 lb 39,200 gr @14 lb
27,500 gr @ 12 lb 35,000 gr @17 lb 43,500 gr @ 20 lb
Efciency at Rated Sales Dosage
5
4 lb. salt dosage: 5 lb. salt dosage 6 lb. salt dosage
4570 gr./lb. 4050 gr./lb. 4150 gr./lb.
Freeboard to Media
2
20.5 - 21.5 in 17 - 18 in 19.75 - 21.75 in
Freeboard to Underbedding
3
42.0 - 42.5 in 39.6 - 40.1 in 53.8 - 54.3 in
Salt Storage Capacity 250 lb or 375 lb 375 lb 375 lb
Rated Service Flow @ Pressure Drop 5.9 gpm @ 12 psi 7.2 gpm @ 12 psi 7.0 gpm @ 13 psi
Total Hardness, Maximum 75 gpg 99 gpg 99 gpg
Total Iron, Maximum (dissolved) 5 ppm 5 ppm 5 ppm
Hardness to Iron Ratio, Minimum 8 gpg to 1 ppm 8 gpg to 1 ppm 8 gpg to 1 ppm
140 mg/L to 1 mg/L 140 mg/L to 1 mg/L 140 mg/L to 1 mg/L
Operating Pressure 20 - 125 psi 20 - 125 psi 20 - 125 psi
140 - 860 kPa 140 - 860 kPa 140- 860 kPa
Operating Pressure (Canada) 20 - 90 psi 20 - 90 psi 20 -90 psi
140 - 620 kPa 140 - 620 kPa 140 - 620 kPa
Operating Temperature 33 - 120°F 33 - 120°F 33 - 120°F
1 - 50°C 1 - 50°C 1 - 50°C
Electrical Requirements 24V/60 Hz 24V/60 Hz 24V/60 Hz
Electrical Power Consumption, Min./Max. 3 Watts/35 Watts 3 Watts/35 Watts 3 Watts/35 Watts
Drain Flow, Maximum
4
1.1 gpm 2.0 gpm 2.1 gpm
Recharge Time, Average 85 min 64 min 64 min
Recharge Water Consumption 23.3 gal 61 gal 65 gal
1 Capacities and corresponding salt dosages pertain to low hardness waters. Capacities given per recharge
2 Measured from top of media to top of inlet tting (backwashed and drained)
3 Measured from top of underbedding to top of inlet tting
4 Backwash at 120 psi (830 kPa)
5 Efciency rating only valid at stated salt dosage on Soft-Minder® models and is efciency rated according to ANSE/
NSF Standard 44.

Culligan MEDALLIST SERIES Specifications

General

Type	Water Softener
Flow Rate	Up to 12 gallons per minute
Resin Type	High-capacity resin
Dimensions	Varies by model
Weight	Varies by model
Tank Material	Fiberglass
