CUMMINS ALLISON JetScan iFX i100 - Product View; Machine Diagram

4 | JetScan iFX
®
i100 scanner | Diagrams
Machine diagram
Pocket
Display
panel
Release
lever
Stacker
wheels
Power
switch
on back
of unit
Feed roller
Pocket mirror
Adjustable hopper guides
Pocket
sensor
Thickness adjustment dial
located behind hopper extension
Feed roller
Hopper
Touch-
screen
display
Release
lever
Stacking
sensor
