SPECIFICATIONS
Model no. 1450 Cable Puller
width 24"
length 19 1/4"
height 15"
weight 119 lbs.
maximum pulling force — 10,000 lbs.
Low Speed High Speed
speeds (approx.) no load — 12 FPM no load — 48 FPM
2,000 lbs. — 11 FPM 1,000 lbs. — 36 FPM
4,000 lbs. — 10 FPM 1,500 lbs. — 29 FPM
6,500 lbs. — 8 FPM 2,000 lbs. — 24 FPM
motor — 120 volts AC, 60 hertz, 20 amps
SPECIFICATIONS — MODEL 1450 CABLE PULLER
45˚
45˚
FEATURES
• One person set up
• Patented 45 degree horizontal pivot allows for use of
puller in tight spaces. See drawing below.
• Built-in force gauge with digital read out and color screen to indicate
force ranges
• Circuit breaker on/off switch — helps protect motor
• Two speeds
• Built-in time delay – helps protect motor
• Puller ready light gives visual confirmation that puller is ready for use
• Safety pawl on capstan sprocket to prevent reverse rotation
• Tapered capstan to help avoid rope overlap
• Tailing rope safety roller for operator safety — lets operator stand out
of the direct line of tight pulling rope
• Two handles for carrying or positioning puller
• Simple electrical system for easy maintenance
• Boom height adjustment handle allows for
easy vertical positioning of boom sections
• Integrated foot switch
Patented
Patent #9,899,811
Boom pivots 45°
in either direction
to fit in tight spaces.
