MAINTENANCE
31
Unplug the cable puller before servicing.
WARNING
DO NOT alter this cable puller. Doing so will void the warranty.
Guards and safety features are provided for your protection.
Capstan
Replace the capstan if it is grooved more than 1/16” deep.
Lubrication
Wheels and casters — Grease as needed with a good quality
multi-purpose grease. Grease fittings are located on the wheel
and caster.
Worm Box Assemby — Grease as needed with a good quality
multi-purpose grease. Start with puller mount in fully upright
(transport) position and insert one pump of grease. Rotate
worm box handle one full turn and insert another pump of
grease. Continue this sequence until puller mount is fully in
the down position. Grease fitting is located on the side of the
worm box assemby.
Inspection
Motor Brushes – Inspect the two motor brushes every 30
hours. Replace if less than 3/8” long. Always replace both
brushes at the same time.
