PARTS LIST – MODEL 1450 GEAR MOTOR
35
ITEM # PART # DESCRIPTION QTY.
1 1000-137 BRUSH ASSEMBLY WITH CAPS 2
2 1000-138 FLANGE NUT 2
3 1000-139 HEYCO STRAIN RELIEF, BLACK, #1287 1
4 1000-140 COMM ENDBELL ASSEMBLY 1
5 1000-141 3 WAVE SPRING (SSB-0138) 1
6 1000-142 MOTOR FRAME 1
7 1000-143 115V ARMATURE AND BEARING ASSEMBLY 1
8 1000-144 1ST STAGE GEAR (PINION) MACHINED/SNAP RINGS (2) 1
9 1000-145 2ND STAGE PINION/GEAR/BEARING ASSEMBLY 1
10
1000-146 3RD STAGE PINION/GEAR/BRG ASSEMBLY 1
11 1000-147 4TH STAGE GEAR/PINION/BRG ASSEMBLY 1
12
1000-148 HIGH SPEED IDLER/BRG ASSEMBLY 1
13
1000-149 GEARCASE GASKET AND DOWEL PINS (2) 2
14
1000-150 CAP SCREW KIT — 3/8–16 × 2 1/4" (3) 1 1/2" (2) 1
15
1000-152 OIL SEAL 1
16
1000-153 DOWEL PINION/4TH GEAR/BEARING ASSEMBLY
1
17
1000-154 OUTPUT PINION/4TH GEAR/BEARING ASSEMBLY
1
18
1000-155 OUTPUT SHAFT AND BEARING ASSEMBLY
1
19
1000-177 FIELD REPLACEMENT KIT
1
20
1000-151 STANDOFF SPACER
2
21
50002-24 SEAL
1
