58909-INS-RA
•
PAGE 4
Step 10
Route the 4-flat to the area near the window
wash fill lid. Locate a suitable position to
mount the 4-flat bracket. Using the bracket as
a template, mark the two holes and drill two
3/32" holes and attach the bracket using the
two remaining screws. Secure the 4-flat to the
frame rail with a cable tie.
WARNING
Take care not to drill through
the body or any exposed surface.
Step 11
Secure any excess wire so that it is not drooping or dangling, but not so tight that it causes unnecessary strain to the wire
which could lead to breakage over time. After removing slack from the 4-flat wire, tighten any zip ties and add as needed.
Use a zip tie to fasten any excess wire to a solid spot along the driver-side inner fender.
Reinstall all items removed during install. If it was disconnected at the beginning of the installation,
reconnect the negative battery terminal. Install the provided 4-flat dust cover to help prevent corrosion.
