Cushcraft HV4E Vertical Antenna
Version 0 4 2024 Cushcraft
WARNING:
Always mount this antenna so that it is out of the reach of adults as well as
children. The capacitance elements (spokes) can cause injury and or severe RF burns.
•
Never
place this antenna in a location that will permit people to encounter the loading spokes or
any other part of the antenna.
•
Never
place this antenna where a mechanical failure might allow the antenna to contact power
lines or other utility wires.
•
Always
ground the feed-line at the point where it enters a building to a good earth ground for
lightning protection.
•
Follow
the guidelines for antenna installations as recommended by the US consumer product
safety commission.
INSTALLATION
The HV-4E was designed as an efficient low profile antenna. The antenna installation MUST be protected
with non-metallic fencing to provide personal safety and to prevent antenna damage. The antenna can
be installed using the supplied mounting bracket and a suitable ground radial system.
IMPORTANT
: A suitable ground plane must be installed with this antenna.
PORTABLE SETUP
The antenna may be disassembled to the extent necessary for transporting to a temporary location.
Before the antenna is disassembled, some type of marks should be placed on the mast of the antenna to
ensure it will be the same height as before. Some retuning may be required after moving the antenna.
The MFJ-1901 MFJ Portable Ground-Coupled Antenna Base is ideal for portable use.
WARNING:
If the antenna falls it will be damaged and may cause serious injury. Whatever
type of installation you choose, remember that the antenna should be installed where it can never
be contacted by people or animals.
MFJ Optional Accessories (not included)
HV-4TB Tilt Base
MFJ-1901 MFJ Portable Ground-Coupled Antenna Base
GKR-6160 or MFJ-1932 Ground Radial Kit
GR-1 or MFJ-1934 Ground Rod
