Cushcraft HV4E Vertical Antenna
Version 0 5 2024 Cushcraft
TOOLS AND TIME REQUIRED FOR ASSEMBLY
The estimated assembly time for this antenna is 1 hour. Antenna assembly requires the following hand
tools:
[ ] 5/16" nut driver
[ ] 7/16" open end wrench
[ ] large wire cutters (to cut aluminum spokes)
[ ] small pliers
[ ] #2 Phillips screwdriver
[ ] suitable eye protection
In addition, you will need two stable supports (i.e. saw horses or trash cans) to aid in assembly.
For installation you will need some additional items not supplied with the antenna installation kit.
[ ] Quality low-loss 50-Ohm coax with a PL-259 to go from the antenna to the transmitter.
[ ] Either an SWR meter or Antenna Analyzer (MFJ-259, 269)
SAFETY PRECAUTIONS:
WARNING:
You can be killed if the antenna, feedline, or the equipment used to install the
antenna accidentally contacts any utility lines. Never install an antenna near power lines!
1. Be careful while carrying the antenna. It is heavy enough to cause you to lose your balance if it is
handled too casually or if the capacitance spokes become entangled in obstructions.
2. Mount the antenna in a way so that it is out of reach. The ends of the capacitance spokes can
cause eye injury, serious RF burns or both.
3. Make sure that a mast, if used, is sturdy enough to support the weight and the wind load.
