Page C-4
Repair and Service Manual
B
BODY
Read all of Section B and this section before attempting any procedure. Pay particular attention to Notices, Cautions, Warnings and Dangers.
Fig. 4 Body Components (Cargo Box, Seat, Foot Rest)
Seat
Bed
Seat Back
Support or
Bed Frame
38
43
41
42
41
43
39
35
36
37
40
38
