Cushman Shuttle 4 - Axle Mounted Steering and Front Suspension

Page E-1
Repair and Service Manual
B
B
FRONT SUSPENSION AND STEERING
Read all of Section B and this section before attempting any procedure. Pay particular attention to Notices, Cautions, Warnings and Dangers.
Fig. 1 Axle Mounted Steering and Front Suspension
Part of Frame
Part of
Frame
Wave Washer
Bearing
Outer Snap Ring
Inner Snap Ring
Intermediate
Shaft with
U-Joints
Rack & Pinion
Unit
King Pin
Tube
Thrust
Washer
Spindle &
King Pin
Bushing
Formed
Axle
Tie Rod
Spacer
Rack Ball Joint
Rack Extension
