Interface description
11.1.
Overview
The connections for the power supply and for the integration into computer systems are
on the backside below of the ergometer.
The following figure shows the integrated connections:

Power supply
including power switch and f
use

DIN round connector or Subd plug ( 9 pin socket )
for the connection of the computer system
0
1
Power Supply
ON / OFF Switch
Fuse
GE-Port
ER-Port
