Ergometer

3000

Interfaces

11.3.

Remote interface

The device can be connected to an external computer system with a RS 232

C serial

interface. The following functions

can be carried out:



Remote

Execution of pc

supported ergometry programs



Acknowledgement of ergometry data

The external computer system can be connected as required to a DIN

round connector or

a Sub

connector. The interface is recognized automatically

Safety instruction:



Only one of the two interfaces must be connected.

The following table describes the major characteristics of the system:

Function

Specification

Notes

Baud rate

2400 Bd ( Custo Control )

4800 Bd ( P10 )

Data format

8 Bit / no

parity /

1 Stopbit

Protocol

Custo Control / P10

cf. interface specification

Isolation

4 kV

cf. DIN EN 60601
