Interfaces
Ergomete
r
ec
3000
11
-
4
The following table shows the allocation of the DIN
-
connector:
Pin
Signal
Notes
1
TxD
2
GND
3
--
4
--
5
RxD
The follow
ing table shows the allocation of the Sub
-
D
-
connector:
Pin
Signal
Notes
1
--
2
RxD
3
TxD
4
--
5
GND
6
ECG signal
optional
7
ECG
-
GND
optional
8
Remote Start ECG device
optional, open collector
9
--
