3.2 Device component: external views
PLUS4 STD
1. Front cover
2. Paper output
3.
4. Release lever for cover
5. Status LED
6. FEED key
7.
8. Connector for extended range module (optional)
9. USB interface connector (miniUSB)
10. Power supply connector
11. RS232/TTL serial interface connector
12. Switch for serial interface setting
5 6 732 41
12111098
14
