4.2 Connections

connected to the device at the same time, communication takes place via the USB port.
ATTENTION: In some using conditions, we recommend the installation of a ferrite core on the power supply cable.
PLUS4 STD
PC
USB device
Power supply
Serial
RS232/TTL
Power supply cable
(optional)
Serial cable
(optional)
USB standard
cable
24
