6.3 Printhead status
The device performs the printhead operating status when printing the setup report. The total number of dots is reported
PRINTER SETTINGS
PRINTHEAD SELFTEST
1 •••••••••• 832
PRINTHEAD WORKING GOOD!
PRINTER TYPE ....................................PLUS4
PRINTING HEAD TYPE ........................<type>
INTERFACE ..........................................RS232
PROGRAM MEMORY TEST.................OK
DYNAMIC RAM TEST...........................OK
SCODE. <code> - rel 1.00
FCODE. <code> - rel 1.00
Total no.
printhead dots
Printhead status,
no damaged
dotsv
PRINTER SETTINGS
PRINTHEAD SELFTEST
1 •••••••••• 832
DEFECTED PRINTHEAD DOTS = 4
DOT POSITION : 2
DOT POSITION : 11
DOT POSITION : 43
DOT POSITION : 72
PRINTER TYPE ....................................PLUS4
SCODE. <code> - rel 1.00
FCODE. <code> - rel 1.00
Total no.
printhead dots
Printhead status
List of
damaged dots
49
