7.0 GFM CONNECTOR PIN ASSIGNMENT
7.1 AUX Connector
The following is the pin out for the AUX Connector.
Pin No.
Function
1 (WHT)
Modbus RS-485 D+ serial port
2 (BRN)
User supplied Power Input VIN+ (12-28 VDC @100 ma)
3 (GRN)
CR-A - Will be active when gas flow is within programmed limits.
4 (YEL)
CR-B – Will be active when gas flow is within programmed limits.
5 (GRY)
User supply power common VCOM
6 (PNK)
Modbus RS485 and Vout analog common
7 (BLU)
Modbus RS-485 D- serial port
8 (RED)
Gas Flow Analog output VOUT+ (0.00 – 2.55 vdc)
