CYBELEC CybTouch 8 - Basic Page Description; Bend Numerical Page Overview

14/38
Sept.
2014
V3.1
Material used and thickness
Current cycle activity information
Tools Management
Bend Correction
Back gauge (X & R axes)
Correction
Start – Stop
More Page
TouchProle Mode (optional)
Menu Button
Auxiliary function button
Interactive message line
Back gauge (R axis)
position value (optional)
Beam (Y axis) position
value / bend angle
Back gauge (X axis)
position / ange length
Add step or next step
Program number
Current step (sequence) number
Repeat sequence button
(inactive here)
Material thickness
Material sigma
Bending length
Dwell time
Crowning
Return to Bend
Numerical Page
Opening (TDC)
Slow speed return
Speed change threshold and bending speed
Access to more functions
Back gauge nger type
Step bending
Force
Back gauge retraction
Next step
Material
CybTouch 8 PS User Manual
More paGe
bend nuMerical paGe
baSiC PaGe deSCriPtion
Bend Numerical Page →
