10
ELECTRICAL INSTALLATION CONT.
CONNECTING THE MAINTENANCE BYPASS PDU TO A UPS
Connect the input/output as shown in the following diagrams for different models
OL5KRTHD/OL6KRTHD
TO NORMAL
AC SOURCE (Utility)
OUTPUT
TO
EQUIPMENT (Load)
OL6KRT
TO NORMAL
AC SOURCE (Utility)
OUTPUT
TO
EQUIPMENT (Load)
OL8KRT/OL10KRT
TO NORMAL
AC SOURCE (Utility)
OUTPUT
TO
EQUIPMENT (Load)
