CyberPower PR750RT2U - Menu; Outlet Control

Item
Default
Option
Description
Night Mode LED Switch
Off
 On
 Off
If On is selected, the LED indicators work normally.
If Off is selected, the LED indicators will turn off after a few
seconds except for Fault Indicator. Pressing any button will
activate the LED Indicators.
Night Mode Maximum
Fan Speed
Full
 Full
 High
 Medium
 Low
Options are shown in bar chart. Select the maximum fan
noise level you can accept in Line mode. This setting is also
related to runtime in battery mode. UPS performs best
backup time when Full is selected. Runtime decreases as
maximum fan speed gets lower than Full.
Menu / Outlet Control
Use this menu to configure UPS outlet performance. Outlets are divided into Critical (CL) and Non-Critical (NCL) outlets. Connect the mission
critical devices into Critical outlets and nonessential equipment into NCL outlets. If equipment needs to be shut down or reboot in a specific
order, plug the equipment into separate outlet groups.
Enter the submenu “Config UPS” to configure the total output of the UPS, including CL and NCL outlets. Enter “Config NCL” if you want to have
additional settings for NCL outlets, for example, cut off the power provision to the nonessential equipment during a blackout to reserve
runtime for mission critical devices.
Item
Default
Option
Description
Delay Turn On
4 seconds
 0-600 seconds
The amount of time that the outlets will wait before actual
startup.
Delay Turn Off
4 seconds
 0-600 seconds
The amount of time that the outlets will wait before actual
shutdown.
Reboot Duration
4 seconds
 4-300 seconds
The amount of time that the outlets will remain off before
the UPS restart itself.
Minimum Restored
Capacity
0%
 0-100%
It is the criteria for UPS to perform auto-restart as utility is
restored. If battery capacity is higher than this setting, the
auto-restart will be performed; otherwise, the UPS will keep
charging the battery until battery capacity reaches that
level.
Uptime on Battery
Disable
 Enable: 5-1800 seconds
 Disable
Set the maximum runtime on battery mode. The UPS will
shut down after the amount of time spent in battery mode
has reaches this setting. Make sure the estimated runtime is
larger than this setting; otherwise, the UPS will still stop
supplying power when it is running out of battery.
Reserved Runtime
Disable
 Enable: 0-1800 seconds
 Disable
When the UPS is in battery mode, it will cut off output
power when the remaining runtime reaches the level.
NCL Switch*
*Can only be configured in
the Submenu, NCL
Configuration.
On
 On
 Delay On
 Off
 Delay Off
 Reboot
 Delay Reboot
This is the main switch for NCL outlet groups.
Off on Overload
*Can only be configured in
the Submenu, NCL
Configuration.
Disable
 Enable
 Disable
NCL outlets will be turned off when the UPS is overloaded in
battery mode if the item is enabled. NCL outlets will turn on
automatically as utility is restored.
LCD OPERATION GUIDE (continued)
