The surge protected communication ports (RJ45) are used to prevent power surges that travel through Ethernet lines from causing damage to
electronics. Connect the Ethernet line from wall jack outlet to the surge protected communication port marked “IN” of the UPS. Then, connect
another Ethernet line from surge protected communication port marked “OUT” of the UPS to the network device.
Connect either the USB cable or Serial cable to the corresponding port on the UPS and on the computer with PowerPanel® Business software
installed. PowerPanel® Business software is available on our website. Please go to www.cyberpowersystems.com/products/software for the
free download.
Note: USB and Serial port cannot be used simultaneously. Serial port will be disabled if the USB port is used.
Additionally, if you would like to control the UPS from a remote location, a CyberPower Remote Management Card (RMCARD) is required. For
more information, visit www.cyberpowersystems.com.
