20
Using the ISOFIX Connect system, you can x the car seat
to the vehicle, thereby increasing your child’s safety. The
child still needs to be secured with the three-point belt of your
vehicle.
• Use the adjustment button (8) under the seat cushion (1) of
the car seat.
• Pull the two ISOFIX Connect locking arms (9) as far as they
will go.
• Now twist the ISOFIX Connect locking arms (9) 180° so
that they are facing the direction of the ISOFIX anchorage
points (7).
• Push the two ISOFIX Connect locking arms (9) into the
ISOFIX anchorage points (7) until these lock into place with
an audible ‘CLICK’.
• Ensure that the car seat is secure by trying to pull it out.
• The green safety indicator (11) must now be clearly visible
on the two release buttons (10).
NOTE! The ISOFIX anchorage points (7) are two metallic
clips for each seat and are positioned between the backrest
and the seating surface of the vehicle seat. In case of doubt,
please refer to the driver’s manual of your vehicle.
NOTE! Before clicking the ISOFIX Connect locking arms
(9) into the ISOFIX anchorage points (7), check the release
buttons (10). If the green safety indicator (11) is visible, you
must rst release the ISOFIX Connect locking arms before
joining by pressing and pulling back the release button (10).
INSTALLING THE CAR SEAT WITH ISOFIX
CONNECT SYSTEM
Installation
1
9
8
10
7
11
