6. Loosen the two screws in the right inner and outer collars using a Phillips screwdriver.
QtyDescription
2Screws1
1Inner collar2
1Outer collar3
1Cover4
7. Slide the inner and outer collars onto the right covers.
8. Insert the tabs of the collars into the slots of the cover.
9. Tighten the two screws using a Phillips screwdriver.
10. Repeat steps 1 through 9 for the right side.
Remove left and right handle assembly
The left and right handle assemblies are shipped in rotated positions. The handle assemblies must be
removed and rotated 180 degrees for proper setup and assembly.
Page 36 of 95
Cybex 771A/771AT, 772A/772AT Arc Trainer Part Number 5771-4 K
