Cybex Owner’s Manual
Connect contact heart rate cable
1. Plug right heart rate cable into main frame socket.
Heart Rate
Wire
Main Frame
Socket
Right Side
Shown
Position plug so handle does not
rubcableduringoperation.
2. Plug left heart rate cable into main frame socket.
Attach foot pads
Have one person lift the unit while a second person places a foot pad under each of the two back
feet.
Foot Pads (2)
