CYBEX Cloud Q Manual

23
Automatic
DO NOT turn
7
8
9
INSTALLING THE BASE USING A LAP AND SHOULDER BELT (Continued)
a
b
6. On the buckle side, first lift up on the shoulder belt to remove
slack in the lap belt . Then remove slack from the shoulder
belt on the opposite side .
At this point, only remove slack from the vehicle belts, being
careful not to over tighten them. The Belt Tensioning Plate will
tighten the system fully.
7. Press the Belt Tensioning Plate down with both hands where
indicated, until it locks into place. The orange Locking Lever
will rotate to the CLOSE position automatically when the
Plate is locked.
If Belt Tensioning Plate does not lock, try loosening the vehicle
belt slightly.
8. Grab the Base at the Belt Guides and pull from side to side and
front to back to make sure it is installed correctly. The Base
should not move more than 2.5 cm in any direction.
If the Base moves too much, open the Belt Tensioning Plate
and remove a little more slack from the vehicle belt, close
Plate and recheck. After this, if the Base still moves too much,
you may need to try a different vehicle seat location.
9. Check that the Recline Angle remained in the appropriate range
for the child's weight. If not, remove Base, adjust recline angle
and reinstall. See page 17.
Make sure that vehicle belt buckle and hardware do not interfere
with correct installation of the Base, or with the connection of the
Infant Carrier to the Base
a
6
b

CYBEX Cloud Q Specifications

General

Certification	ECE R-44/04, Supplement 7
Mounting type	ISOFIX
Product color	Gold
Car seat group	0+ (0 - 13 kg; 0 - 15 months)
Adjustable backrest	Yes
Belt fastening type	5-point

Weight and Dimensions

Depth	665 mm
Width	440 mm
Weight	5400 g
Height (max)	570 mm
Height (min)	403 mm
