CYBEX Cloud Q Manual

1. Loosen Harness by firmly pressing down on the
Harness Adjustment Button while pulling forward
on both straps at shoulder level .
2. Press red button on Harness Buckle to release Tongues.
3. Place child in Infant Carrier in seated position making
sure their bottom is in the seat, and their back is fully
supported.
4. Pull Harness straps over each arm onto shoulders and
around the hips. Make sure Buckle Pad and Harness
Buckle are between the legs.
Newborns tend to draw arms and legs close to their
bodies. Gently extend each limb to allow for proper
Harness positioning. Be mindful of especially sensitive
areas (e.g. bellybuttons, circumcisions).
5. Buckle by inserting one Tongue at a time into the
Harness Buckle listening for an audible CLICK on the
second one. Make sure Harness Straps are not twisted.
a
b
18
CLICK!
CLICK!
5
2
3
1
4
a
b
MAKE SURE Harness straps are LEVEL WITH or just ABOVE child's shoulders.
If not, refer to page 7.
ALWAYS check Harness Buckle to make sure it is securely latched. Failure to
fasten and tighten the Harness system correctly with each use can result in
DEATH or serious injury.
USING THE INFANT CARRIER - SECURING THE CHILD

CYBEX Cloud Q Specifications

General

Certification	ECE R-44/04, Supplement 7
Mounting type	ISOFIX
Product color	Gold
Car seat group	0+ (0 - 13 kg; 0 - 15 months)
Adjustable backrest	Yes
Belt fastening type	5-point

Weight and Dimensions

Depth	665 mm
Width	440 mm
Weight	5400 g
Height (max)	570 mm
Height (min)	403 mm
