CYBEX Cloud Q Manual

26
3
b
a
5
RELEASING INFANT CARRIER FROM BASE
If used, retract the L.S.P. device. See page 27
1. Disconnect the Tether Loop from the Attachement
Hook
3. Move the carry handle into the CARRY position
4. Press the green Safety Button in while
pushing the Infant Carrier Release down
5. Slightly tilt Infant Carrier toward front of vehicle.
Grasp Infant Carrier with both hands to lift off.
a
b
1
4
2. Roll the Tether Loop and place it in the Tether
Loop Storage Pocket
2

CYBEX Cloud Q Specifications

General

Certification	ECE R-44/04, Supplement 7
Mounting type	ISOFIX
Product color	Gold
Car seat group	0+ (0 - 13 kg; 0 - 15 months)
Adjustable backrest	Yes
Belt fastening type	5-point

Weight and Dimensions

Depth	665 mm
Width	440 mm
Weight	5400 g
Height (max)	570 mm
Height (min)	403 mm
