CYBEX Cloud Q Manual

1. Position Base on a rear vehicle seat.
2. Adjust the Leveling Foot to achieve the correct angle
range for your child's weight as shown on the Level
Indicator. See page 21
3. Fully open Belt Tensioning Plate by turning the orange
Locking Level to the position and lifting up
on the Plate.
Once open, the Belt Tensioning Plate will remain open
on its own. The Locking Lever should be in the
position with the Plate open
4. Pull out vehicle belt to form a single length of about
60 cm Hold the buckle Tongue in one hand and
squeeze the lap and shoulder belts together in the
other.
5. Route the vehicle belts under the Belt Tensioning Plate,
and through the blue REARFACING SEATBELT PATH
on both sides of the Base. BUCKLE THE BELT.
Make sure the belts lay flat and are not twisted.
The vehicle belt should ALWAYS be routed UNDER the
tab on the Belt Guide. NEVER place a vehicle belt over
the tab on the Belt Guide, even in a vehicle with longer
buckle stalks.
OPEN
22
INSTALLING THE BASE USING A LAP AND SHOULDER BELT
OPEN
5
60 cm
4
3
2
Front of vehicle
1
blue REARFACING SEATBELT
PATH labels

CYBEX Cloud Q Specifications

General

Certification	ECE R-44/04, Supplement 7
Mounting type	ISOFIX
Product color	Gold
Car seat group	0+ (0 - 13 kg; 0 - 15 months)
Adjustable backrest	Yes
Belt fastening type	5-point

Weight and Dimensions

Depth	665 mm
Width	440 mm
Weight	5400 g
Height (max)	570 mm
Height (min)	403 mm
