CYBEX Cloud Q User Manual

1. Position the infant carrier on a rear vehicle seat, with the
handle in the DRIVE position, with the foot end towards
the backseat, push it rmly against the vehicle seat.
2. Route the lap belt portion of the seat belt into the belt guides
on BOTH THE HANDLE AND CARRIER. Make sure the
belt is correctly routed on both sides and buckle the belt.
3. Lift shoulder belt over handle and around Carrier. Slide shoulder
belt into the blue Shoulder Belt Guide
a
Make sure the
shoulder belt passes below the L.S.P. devices on both sides.
4. LOCK your vehicle lap shoulder belt. Refer to
your vehicle Owner's Manual
for how your
vehicle lap and shoulder belt locks.
In many vehicles, you can switch the shoulder belt retractor into locking
mode by pulling the shoulder belt out all the way. In some vehicles the
buckle locks. Check the vehicle Owner’s Manual to see how your
system locks.
To check if the vehicle belt is locked, after you install the infant carrier, pull
up rmly on the lap belt between the Belt Guides. The belt should remain
tight if the vehicle system is locked.
5. Push Infant Carrier rmly into vehicle seat pressing down
near the crotch strap between the child’s legs
a
, while
removing slack from lap belt. Repeat for shoulder belt.
b
6. Make sure that vehicle belt buckle and hardware
DO NOT INTERFERE with the Infant Carrier.
37
a
b
a
2
3
4
5
1
6
CLICK!
NEVER install this child restraint using a non-locking
vehicle lap shoulder belt. A locking clip must be used
with a vehicle belt that DOES NOT LOCK. Call the
CYBEX Customer Care Department at 1.877.242.5676 to
obtain a locking clip.
INSTALLING INFANT CARRIER ONLY WITH A LAP/SHOULDER BELT

CYBEX Cloud Q Specifications

General

Certification	ECE R-44/04, Supplement 7
Mounting type	ISOFIX
Product color	Gold
Car seat group	0+ (0 - 13 kg; 0 - 15 months)
Adjustable backrest	Yes
Belt fastening type	5-point

Weight and Dimensions

Depth	665 mm
Width	440 mm
Weight	5400 g
Height (max)	570 mm
Height (min)	403 mm
