CYBEX Cloud Q User Manual

7. Make sure the vehicle is on level ground. Check the recline
angle. Adjust the seat angle until the red line on the Infant
Carrier is level with the ground. A tightly rolled towel or
pool noodle may be placed under the Infant Carrier near
the vehicle seat back to adjust the angle. See page 43.
The Cloud Q is allowed to touch the vehicle seat(s) in front of it, as
long the recline angle of the Cloud Q is not affected.
8. Grab the Infant Carrier at the Belt Guides and pull
from side to side and front to back to make sure it
is installed correctly. The Infant Carrier should not
move more than 1 inch (2.5 cm) in any direction.
If the Infant Carrier moves too much, tighten the vehicle belts more
and recheck. You may try a different vehicle seat or installation
method, or both.
9. If the Infant Carrier is next to a vehicle door or panel,
extend the adjacent L.S.P. device. See page 42.
FRONT OF VEHICLE
38

(Image shown from opposite side
compared to illustrations to the left)
LINE MUST BE LEVEL WITH GROUND
WHEN INSTALLED WITHOUT BASE
FRONT OF VEHICLE
LINE MUST BE LEVEL WITH GROUND
WHEN INSTALLED WITHOUT BASE
FRONT OF VEHICLE
7
9
ALWAYS have the handle locked in the DRIVE position
while using this child restraint in a vehicle.
FRONT OF VEHICLE
INSTALLING INFANT CARRIER ONLY WITH A LAP/SHOULDER BELT
EN

CYBEX Cloud Q Specifications

General

Certification	ECE R-44/04, Supplement 7
Mounting type	ISOFIX
Product color	Gold
Car seat group	0+ (0 - 13 kg; 0 - 15 months)
Adjustable backrest	Yes
Belt fastening type	5-point

Weight and Dimensions

Depth	665 mm
Width	440 mm
Weight	5400 g
Height (max)	570 mm
Height (min)	403 mm
