Cybex Free Weight Owner’s Manual
Service
Page 7-52
5570 and 5571 - Squat Rack With Adjustable Stop
1 1 5570-201 Left Hand Side Assembly
2 1 5570-200 Right Hand Side Assembly
3 Removed
4 1 5570-202 Lower Brace
5 1 5570-203 Upper Brace
6 2 5572-200 Bar Stop
7 8 JC782834 SHCS .50-13 x 3.00
8 4 JC782840 SHCS .50-13 x 4.00
9 12 HN784900 Locknut .50-13
10 2 5420-029 Adjustable Bar Assembly
11 8 01066 Plastic Fastener
12 2 5570-205 Barbell Holder
13 2 5570-310 Bumper
14 2 JC780417 BHSCS .50-13 x 1.00
15 2 JS388300 Lockwasher .50-13
16 Removed
17 4 5570-206 Detent Pin
18 2 5570-309 Bumper
ITEM QTY PART NO. DESCRIPTION
19 2 PP080202 Hole Plug 1.19 Dia. x 11 G
20 2 PP090210 Insert
21 2 PP090206 Insert
22 2 5572-304 Bumper
23 Removed
24 2 PN660200 Hole Plug
25 10 5330M040 Hole Plug
26 2 PN660201 Hole Plug
27 2 5340P003 Weight Tube 6”
28 4 5490P010 Weight Tube 8”
29 4 5490P009 Weight Tube 10”
30 1 3900-445 Cybex Decal 1.00 Horiz. Black
30 Removed 7-03
30 1 3900-446 Cybex Decal 1.00 Horiz. Silver
31 1 5220-365 Warning Decal
32 10 5220-367 Spacer
33 1 55571 Squat Rack Instr. (not shown)
ITEM QTY PART NO. DESCRIPTION
To Next Page
