Cybex Free Weight Owner’s Manual
Service
Page 7-4
5208 - Bent Leg Ab Board
1 1 4000M218 Detent Pin
2 1 5208M040 Lower Pivot Shaft
3 1 5208M041 Upper Pivot Shaft
4 1 5208P042 Adjusting Post
5 1 5208P043 Spring Guide Rod
6 1 5208P044 Latch Bolt
7 2 5208M045 Wear Pad
8 1 5208M046 Grip 12.75 L
9 2 5208P048 Spacer
10 1 5208Y083 Right Hand Placard Decal
11 1 5208Y084 Left Hand Placard Decal
12 1 BS070201 Compression Spring .56 x .66 x .50 L
13 3 BS110200 Die Spring 1.23 x .65 x 2.07 L
14 1 3900-445 Cybex Decal 1.00 Horiz. Black
14 1 3900-446 Cybex Decal 1.00 Horiz. Silver
14 Removed 7-03
15 2 CM000219 Angle Adjust Caution Decal
16 1 FB030211 Cam Follower Bearing .75
17 2 FB050209 Flange Bearing 1.00 x 1.25 x .75 L
18 1 HC621228 HHCS .25-20 x 2.25
19 1 HC702822 SHCS .375-16 x 1.50
20 2 HC701224 HHCS .375-16 x 1.75
21 1 HD403326 Shoulder Bolt .625 x 2.00 .50-13
22 1 HD423348 Shoulder Bolt .75 x 4.75 .625-11
23 1 HN624100 Hex Nut .25-20
24 1 HN784000 Hex Nut .50-13
25 4 HN814400 Jam Nut .625-11
26 1 HS308300 Split Lockwasher .25
27 1 GP000002 Pulley Shoulder Adapter
28 2 HS348300 Split Lockwasher .375
29 10 HT102214 Tap Screw #10-12 x .625 A (Phillips)
30 2 HY662912 Set Screw .312-18 x .50 Cup point
31 1 JN714200 Hex Nut .375-24
32 1 JN814200 Hex Nut .625-11
33 4 JS407100 Machinery Bushing .625
34 1 JS408400 Split Lockwasher .625
35 4 PN660200 Plastic Insert 1.00 Dia. x 11 G
36 3 PP080202 Plastic Insert 1.19 Dia. x 11 G
37 4 PP090001 Plastic Insert 1.50 x 2.50 x 11 G
38 1 PP090210 Plastic Insert 2.00 Sq x 10-14 G
39 1 PP090202 Plastic Insert 1.50 x 3.00 x 11 G
40 2 PP400200 Foot Pedal Grip
41 1 PP460200 Plastic Knob .312-18
42 1 PR060003 Recess Bumper
43 2 PP080207 Plastic Insert .437 Dia. x 11 G
44 2 5208C049 Guard
45 1 HN784400 Jam Nut .50-13
46 1 5208W002 Base
47 1 5208W008 Bench
48 1 5208W017 Adjusting Tube
49 1 5208W020 Foot Lever
50 1 5208W026 Lower Adjustment
51 1 5208W037 Cushion Plate
52 1 5208S052-0 Bench Cushion
53 1 5208S060-0 Leg Cushion
54 1 5208S069-0 Contour Cushion
55 2 HC701236 HHCS .375-16 x 3.25
56 2 HS010000 Screw Cap Washer .375
57 8 JC700420 BHSCS .375-16 x 1.25
58 4 JC700936 FHSCS .375-16 x 3.25
59 2 PP080005 Screw Cap
60 1 4121K117 Detent Pin Kit
61 1 5220-364 Warning Decal
62 1 5208-302 Adjusting Tube Decal
63 1 51198 Strength Warranty Sheet (not shown)
64 10 JS347400 Internal Tooth Lockwasher
ITEM QTY PART NO. DESCRIPTION
