Cybex Free Weight Owner’s Manual
Technical
Specifications
Page 2-1
2 - Technical Specifi cations
General Specifications
Frame Finish
Shall be made of mechanical quality 11 gauge and 16 gauge steel purchased in mill run quantities to
assure the best consistency.
Prior to applying fi nish, each part shall be put through a multi-stage wash to remove all oils and to
chemically prepare the surface for maximum adhesion. After the wash, the frames shall be dried and
coated with an Electrostatically applied powdercoat fi nish that shall be applied in powder form and
then baked until cured.
The fi nish shall be textured and very hard, assuring a scratch and chip resistant fi nish.
Handgrips
Machines shall use a closed-end PVC closed cell foam vinyl sleeve.
Diameter should be 1 3/8” to increase comfort through reduced pressure.
Frame Construction
Primarily 1 1/2” x 2” tubing with 11 gauge wall thickness, but different tubing sizes and wall thickness
shall be used as required through engineering stress analysis.
Fully welded frames for maximum structural integrity and minimum maintenance.
Hardware
All 3/8” socket head cap screws shall be of grade 8 (or equivalent). All bolts shall be either chromed
or zinc plated for additional corrosion resistance.
•
•
•
•
•
•
•
•
