Assembly
Page 5-6
Cybex Free Weight Owner’s Manual
Figure 2
ITEM QTY PART NO. DESCRIPTION
1 1 5420C012 Knurled Support Bar
2 1 5420C013 Smooth Support Bar
3 2 5420-027 Adjusting Bar
4 4 HS387700 Washer SAE .50
5 4 JC780417 BHSCS .50-13 x 1.00
6 4 PP080202 Plastic Insert 1.19 Dia.
7 4 PP080208 Plastic Insert
8 1 5420-002 Right Hand Lock Assembly
9 1 5420-003 Left Hand Lock Assembly
28 1 55420 Assembly Instructions
(not shown)
To Next Page
