CYBEX Pro3 - Page 50

Cybex Pro
3
Treadmill Owner’s Manual
Setup
and
Assembly
Page 5-4
Check off ( 9 ) each item in the hardware pack as you fi nd it. See Figure 2. C.
432
8x
1x
2x 8x
5
4
2
6
2
3
7
1
2
4
2
Figure 2
432
8x
1x
2x 8x
Hardware - Actual Size
Item Qty Part Number Description
2 8 HS-16929 Screw, hex head whiz-lock 3-8-16 x 5-8
3 2 HS-16950 Screw, button head 5-16-18 x 7-8
4 8 HS-16939 Screw, Phillips head sems 10-32 x .75
8 1
HX-00438 Allen wrench, 3/16”
