Cyrus 8 DAC - MAIN PCB PART LIST; Transistors

MAINPCBPARTLIST
©CyrusAudioLtdJun2014 30 Cyrus6DAC,Cyrus8DACservicemanualIssue1
C305 RB.2/.5 47uF EL100V20% RJ4series105degC
C306 RB.2/.5 47uF EL100V20% RJ4series105degC
C307 RB.2/.5 47uF EL100V20% RJ4series105degC
C308 RB.3/.7 3300uF EL50V20% RJ4series105degC
C309 RB.3/.7 3300uF EL50V20% RJ4series105degC
C310 RB.2/.4 100uF EL100V20% ECA2AHG101B
C311 SMD0805 10nF CP50V10% X7Rdielectric
C312 RB.2/.4 100uF EL100V20% ECA2AHG101B
C313 SMD0805 10nF CP50V10% X7Rdielectric
C314 SMD0805 680pF CP50V5% NPOdielectric
C315 RB.2/.4 100uF EL50V20% PXseries105degC
C316 RB.2/.2 22uF EL50V20% RJ4series105degC
C400 CAPSMD5.0 47uF 16VEL20% EEEFK1C470UR
C401 RAD0.2 100nF PE100V10% MKTR.82
C402 RAD0.2 100nF PE100V10% MKTR.82
C403 RAD0.2 100nF PE100V10% MKTR.82
C404 RAD0.2 100nF PE100V10% MKTR.82
C405 CAPSMD5.0 33uF 25VEL20% EEEFKE330UAR
C406 AM 10000uF 71V20% AMSERIES40X50mm
C407 AM 10000uF 71V20% AMSERIES40X50mm
C408 SMD0603 100nF CP50V10% X7Rdielectric
C409 SMD0603 100nF CP50V10% X7Rdielectric
C410 RAD0.2 100nF PE100V10% MKTR.82
C411 CAPSMD5.0 47uF 16VEL20% EEEFK1C470UR
C414 SMD0805 100nF CP100V10% X7Rdielectric
C415 RB.2/.4 1000uF 16VEL20% YXJseries105degC
C416 RB.2/.3 220uF EL16V20% RJ4series105degC
C417 CAPSMD5.0 47uF 16VEL20% EEEFK1C470UR
C420 RB.2/.3 220uF EL16V20% RJ4series105degC
C424 SMD0805 220nF CP50V10% X7Rdielectric
C428 SMD0805 220nF CP50V10% X7Rdielectric
C429 SMD0805 470pF CP50V5% NPOdielectric
C430 SMD0603 100nF CP50V10% X7Rdielectric
C431 SMD0603 100nF CP50V10% X7Rdielectric
C434 SMD0603 100nF CP50V10% X7Rdielectric
C440 SMD0805 100nF CP100V10% X7Rdielectric
C450 RB.2/.5 2200uF EL35V20%
FCSeries(EEUFC1V222)
105degC
C451 RB.2/.5 2200uF EL35V20%
FCSeries(EEUFC1V222)
105degC
C460 RB.2/.5Notfitted
C461 RB.2/.5Notfitted
C462 SMD0603 100nF CP50V10% X7Rdielectric
C501 SMD0805 10nF CP50V10% X7Rdielectric
C504 SMD0603 100nF CP50V10% X7Rdielectric

Key:CP=ceramicplate.EL=electrolytic.PE=polyester.PP=polypropylene.BP=bi‐polar.
CAPSMD6.3referstosurfacemountdevicewith6.3mmpitchpads
SMD‐0805referstosurfacemountdevicesizecode0805
DIODES

D107 SOT23 BAV99 300mASignaldiode
D108 SOT23 BAV99 300mASignaldiode
D109 SOT23 BAV99 300mASignaldiode
D110 SOT23 BAV99 300mASignaldiode
D111 SOT23 BAV99 300mASignaldiode
D112 SOT23 BAV99 300mASignaldiode
D113 SOT23 BAV99 300mASignaldiode
D114 SOT23 BAV99 300mASignaldiode
D115 SOT23 BAV99 300mASignaldiode
