MAINPCBPARTLIST
©CyrusAudioLtdJun2014 31 Cyrus6DAC,Cyrus8DACservicemanualIssue1
D116 SOT23 BAV99 300mASignaldiode
D117 SOT23 BAV99 300mASignaldiode
D118 SOT23 BAV99 300mASignaldiode
D130 SOT23 BAS19 300mASignaldiode
D131 SOT23 BAS19 300mASignaldiode
D150 SOT23 BAS19 300mASignaldiode
D151 SOT23 BZX84‐C5V1 300mA5V1Zenerdiode
D152 SOT23 BAV99 300mASignaldiode
D202 SOT23 BAS19 300mASignaldiode
D204 SOT23 BAS19 300mASignaldiode
D205 SOT23 BZX84‐C12 300mA12VZenerdiode
D206 1SR154‐400 1ARectifierDiode
D207 1SR154‐400 1ARectifierDiode
D208 1SR154‐400 1ARectifierDiode
D209 1SR154‐400 1ARectifierDiode
D212 SOT23 BZX84‐C12 300mA12VZenerdiode
D213 SOT23Notfitted
D215 SOT23 BZX84‐C9V1 300mA9V1Zenerdiode
D216 SOT23 BZX84‐C5V1 300mA5V1Zenerdiode
D217 SOT23 BZX84‐C5V1 300mA5V1Zenerdiode
D218 SOT23 BAS19 300mASignaldiode
D219 SOT23Notfitted
D221 SOT23 BZX84‐C5V1 300mA5V1Zenerdiode
D222 SOT23 BZX84‐C5V1 300mA5V1Zenerdiode
D224 SOT23 BAS19 300mASignaldiode
D225 SOT23 BZX84‐C9V1 300mA9V1Zenerdiode
D226 SOT23 BZX84‐C9V1 300mA9V1Zenerdiode
D230 SOT23 BZX84‐C9V1 300mA9V1Zenerdiode
D303 SOT23 BAS19 300mASignaldiode
D304 SOT23 BAS19 300mASignaldiode
D306 SOT23 BZX84‐C10 300mA10VZenerdiode
D307 SOT23 BZX84‐C10 300mA10VZenerdiode
D308 1SR154‐400 1ARectifierDiode
D309 1SR154‐400 1ARectifierDiode
D310 SOT23 BZX84‐C33 300mA33VZenerdiode
D311 SOT23 BZX84‐C33 300mA33VZenerdiode
D312 1SR154‐400 1ARectifierDiode
D313 1SR154‐400 1ARectifierDiode
D314 SOT23 BAS19 300mASignaldiode
D315 SOT23 BAS19 300mASignaldiode
D316 SOT23 BZX84‐C3V3 300mA3V3Zenerdiode
D400 RS2004MDiodebridge
D401 1SR154‐400 1ARectifierDiode
D402 1SR154‐400 1ARectifierDiode
D403 1SR154‐400 1ARectifierDiode
D404 1SR154‐400 1ARectifierDiode
D405 SOT23 BAS19 300mASignaldiode
D406 SOT23 BAS19 300mASignaldiode
D407 1SR154‐400 1ARectifierDiode
D408 1SR154‐400 1ARectifierDiode
D413 SOT23 BAS19 300mAsignaldiode
D416 SOT23 BAS19 300mAsignaldiode
D431 SOT23 BAS19 300mAsignaldiode
D448 DF04S 1A400vSMDBridge
