EN / CZone® Control X User & Installation Manual
10 Technical Specifications
Specifications
Circuit protection Software Fusing (Configurable using CZone Configuration Tool)
NMEA2000 connectivity 1 x CAN Micro-C port, 1 LEN
Output wire range 0.5 - 6mm (24AWG – 8AWG)
Maximum current 120A Total Module Current
Power consumption max 200mA
Power consumption sleep <5mA
Reverse Motor Control
Control X:0
Control X PLUS: 2
RGBW Zones
Control X:1
Control X PLUS: 2
Circuit Current Monitoring All Output Channels
Bilge Pump Running Detection All High Side Output Channels
Addition Inputs Shunt/State Of Charge, Multiplex Switch Inputs
Power supply M6 (1/4") Positive Terminal (9-32V)
Network Supply voltage 9-16V via NMEA2000
Circuit bypass Electronic via Capacitive Touch Panel
Ingress protection IPx7 (mounted vertical on bulkhead and flat)
Compliance
Ignition protected, CE, RCM, NMEA2000, UK-CA (with connectors,
connector plugs and dipswitch cover fitted)
Warranty period 2 years
Operating temperature range -15C to +55C (-5F to +131F)
Storage temperature range -40C to +85C (-40F to +185F)
Dimensions W x H x D 246.5mm x 137.4mm x 54.0mm
Weight Control X:792g, Control X PLUS: 810g
