15D-Link DAP-1860 User Manual
Section 2 - Installation
The Status/WPS LED will turn solid green when the DAP-1860 has connected successfully to a wireless network and is extending
that network. If the Smart Signal LED has a single amber bar after the connection process has nished, the DAP-1860 has
established a poor quality connection. The more lit bars on the Signal Indicator LED, the better the wireless signal. To improve the
connection quality, the DAP-1860 should be relocated closer to the source wireless router. If the extender has been congured as an
Access Point and is connected via Ethernet cable to an uplink network, the Smart Signal LED will not be lit.
Poor Ok Good Best
Optimize Extender Location

D-Link AC2600 Specifications

General

Wireless Standard	IEEE 802.11ac
Ethernet Ports	1 x Gigabit Ethernet
MU-MIMO	Yes
Product Type	Wi-Fi Range Extender
Beamforming Technology	Yes
Frequency Bands	2.4 GHz, 5 GHz
Antenna Type	External antennas
Security	WPA/WPA2
Data Transfer Rate	AC2600 (800 Mbps on 2.4 GHz + 1733 Mbps on 5 GHz)
Maximum Speed	1733 Mbps (5 GHz) + 800 Mbps (2.4 GHz)
