D-Link AC2600 User Manual

47D-Link DAP-1860 User Manual
Section 4 - Connecting a Wireless Client
To connect to a wireless network using Windows 10, you will need to know the wireless network name (SSID) and Wi-Fi
password (security key) of the device you are connecting to.
To join an existing network, locate the wireless network icon in the taskbar, next
to the time display and click on it.
Wireless Icon
Clicking on this icon will display a list of wireless networks which are within range
of your computer. Select the desired network by clicking on its SSID.
Connecting to a Wireless Network
Windows® 10

D-Link AC2600 Specifications

General

Wireless Standard	IEEE 802.11ac
Ethernet Ports	1 x Gigabit Ethernet
MU-MIMO	Yes
Product Type	Wi-Fi Range Extender
Beamforming Technology	Yes
Frequency Bands	2.4 GHz, 5 GHz
Antenna Type	External antennas
Security	WPA/WPA2
Data Transfer Rate	AC2600 (800 Mbps on 2.4 GHz + 1733 Mbps on 5 GHz)
Maximum Speed	1733 Mbps (5 GHz) + 800 Mbps (2.4 GHz)
