DAP-1150 Wireless Access Point Supporting Router Mode
User Manual
Configuring Device (Router Mode)
If needed, specify additional settings for your PPTP + Dynamic IP or L2TP + Dynamic IP WAN
connection.
Parameter Description
Encryption
Select a method of MPPE encryption.
• No encrypt: MPPE encryption is not applied.
• MPPE 40/128 bit: MPPE encryption with a 40-bit or 128-bit
key is applied.
• MPPE 40 bit: MPPE encryption with a 40-bit key is applied.
• MPPE 128 bit: MPPE encryption with a 128-bit key is
applied.
MPPE encryption can be applied only if the MSCHAP,
MACHAPv2, or AUTO value is selected from the
Authentication algorithm drop-down list.
Authentication
algorithm
Select a required authentication method from the drop-down list or
leave the AUTO value.
MTU
The maximum size of units transmitted by the interface.
Keep Alive
Select the checkbox if you want the access point to keep you
connected to your ISP even when the connection has been inactive
for a specified period of time. When the checkbox is selected, the
LCP interval and LCP fails fields are available. Specify the
required values.
Extra options
Advanced options of the pppd daemon which need to be specified
for this connection. Optional.
Dial on demand
Select the checkbox if you want the access point to establish
connection to the Internet on demand. In the Maximum idle time
field, specify a period of inactivity (in seconds) after which the
connection should be terminated.
PPP debug
Select the checkbox if you want to log all data on PPP connection
debugging.
IP received The IP address assigned by the ISP.
Click the Next button to continue.
Page 91 of 175
