Nuclias Connect
4
Nuclias Connect
Introduction
Nuclias Connect is D-Links centralized management solution for Small-to-Medium-Sized Business (SMB) networks. Nuclias Connect makes it easier
to analyze, automate, congure, optimize, scale, and secure your network — delivering the convenience of an Enterprise-wide management
solution, at an SMB price. Nuclias Connect gives you the nancial and technical exibility to expand from a small network to a larger one (up
to 1,000 APs), while retaining a robust and centralized management system. And with its intuitive Graphical User Interface (GUI), a wealth of
enhanced AP features, and a setup wizard that supports 11 languages, Nuclias Connect minimizes the hassle of deployment, conguration,
and administration tasks.
Deployable on Windows server (or Linux via Docker), PC, or Smartphone (via lite management app) the Nuclias Connect free-to-download
software is capable of managing up to 1,000 Access Points (APs) without licensing charges, coupled with an inexpensive optional
hardware controller (The Hub) suitable for remote locations. Through software-based monitoring and remote management of all wireless Access
Points (APs) on your network, Nuclias Connect oers tremendous exibility compared to traditional hardware-based unied
management systems. Conguration can be done remotely. Network trac analytics are available at a glance (in whole or in part). Load Balancing,
Airtime Fairness, and Localized Throttling are enabled.
Nuclias Connect supports multi-tenancy, so network admins can grant localized management authority for local networks. In addition, because
APs can support 8 SSIDs per radio (16 SSIDs per dual band APs), administrators have the option of using one SSID to create a guest network for
visitors.
Nuclias Connect provides direct AP discovery and provisioning when it shares the same Layer-2/Layer-3 network with a given AP, allowing
users to nd APs and import proles with minimum eort, which can be applied as needed to groups or individual APs for even more eective
conguration.
Since Nuclias Connect’s software operates transparently on the network, an AP can be deployed anywhere in an NAT environment. Admins can
provide & manage a variety of distributed deployments, including setting & admin account conguration for each deployment.
Nuclias Connect allows for multiple user authentications while enabling specic access control congurations for each SSID, giving admins the
option of conguring separate internal networks for dierent subnets, while enabling more advanced Value-Added Services, such as Captive
Portal or Wi-Fi Hotspot.

Table of Contents

Other manuals for D-Link DAP-2662

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the D-Link DAP-2662 and is the answer not in the manual?

D-Link DAP-2662 Specifications

General IconGeneral
2.4 GHzYes
Frequency band2.4, 5 GHz
Transmitting power26 dBmW
Networking standardsIEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3af
Ethernet LAN data rates10, 100, 1000 Mbit/s
Maximum data transfer rate1200 Mbit/s
Maximum data transfer rate (5 GHz)867 Mbit/s
Maximum data transfer rate (2.4 GHz)300 Mbit/s
Security algorithms-
Number of SSID supported16
WAN connectionEthernet (RJ-45)
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports1
Antenna typeInternal
Antennas quantity2
Antenna gain level (max)3.8 dBi
PlacementCeiling, Table, Wall
Product colorWhite
Number of products included1 pc(s)
Package depth248 mm
Package width208 mm
Package height73 mm
Package weight390 g
Pallet width1100 mm
Pallet length1200 mm
Pallet height (air)2011 mm
Pallet gross weight (air)174000 g
Quantity per pallet (air)420 pc(s)
Shipping (inner) case width383 mm
Shipping (inner) case height268 mm
Shipping (inner) case length431 mm
Shipping (inner) case weight4000 g
Shipping (inner) case net weight3900 g
Number of cartons per pallet (air)42 pc(s)
Quantity per shipping (inner) case10 pc(s)
Harmonized System (HS) code85176990
Weight and Dimensions IconWeight and Dimensions
Width- mm
