Hardware Overview
7
Hardware Overview
LEDs Connections
2 Power Receptor Connect the supplied power adapter.
3 LAN (PoE) Port
Connect to a Power over Ethernet (PoE) switch or router
via an Ethernet cable.
4 Reset Button
Press and hold for ve seconds to reset the access point
to the factory default settings. Press and hold for one
second to reboot the access point.
1 Power/Status
Solid Red Indicates the access point has malfunctioned.
Blinking Red This LED will blink during boot-up.
Solid Green
Indicates that the DAP-2662 is working
properly.
To Next Page
