8D-Link DCS-2310L User Manual
Section 1: Product Overview
Front
Hardware Overview
1 Camera Lens Records video of the surrounding area.
2 ICR Sensor
The IR-Cut Removable sensor measures the lighting conditions and switches
between color and infrared accordingly.
3 IR LED Infrared LED illuminates the camera's eld of view at night.
4 Microphone Records audio from the surrounding area.
5 PIR Passive Infrared sensor for motion detection.
6 Power/Status LED Indicates the camera's current status.
1
4
5
3
6
2
