15D-Link DCS-936L User Manual
Section 2 - Installation
4
5
6
Step 6
Attach the camera to the camera base and pull the power cable to remove the extra cable. Adjust the angle
of the camera as desired.
Step 5
Place the camera base over the holes that are in the wall and use the supplied screws to attach the camera
base to the surface of the wall. Plug in the microUSB power cable to the camera.
Step 4
Pull the power cable through the middle of the camera base and through the cable channel as shown.
