D-Link DCS-936L User Manual

47D-Link DCS-936L User Manual
Section 3 - Conguration
SD Management
Here you may browse and manage the recorded les which are stored on the microSD card. Click on a folder or le to open it.
SD Card:
SD Status:
Files Per Page:
Refresh:
Format SD
Card:
Deleting Files
and Folders:
This shows the current folder on the microSD card that you are viewing.
Click on an earlier folder name to return to it.
This shows the current microSD card status.
Use the drop-down box to specify how many les to show per page. To
change pages, use the drop-down box on the right.
Click this to refresh the le and folder information from the microSD card.
Click this button to automatically format the microSD card.
Note: SD Recording must be disabled in order to format the microSD
card. See SD Recording on page 43 for more details.
To delete les and folders, click on the checkbox next to the les or folders
you want to delete, then click the Delete button. To select all of the les
or folders shown, click on the checkbox next to the Delete button.

D-Link DCS-936L Specifications

General

Total megapixels	1 MP
Maximum resolution	1280 x 720 pixels
Time stamp overlay	Yes
Supported video modes	720p
Image quality adjustment	Brightness, Colour depth, Contrast, Saturation, Sharpness
Video compression formats	H.264, M-JPEG
Supported graphics resolutions	320 x 176, 640 x 352, 1280 x 720 (HD 720)
Sensor type	CMOS
Optical sensor size	1/4 \
Interface	Wi-Fi
Form factor	Cube
Mounting type	Ceiling/wall
Product color	Black
LED indicators	Power, WLAN
Type	IP security camera
Certification	CE, CE LVD, FCC B, ICES, C-Tick
Placement supported	Indoor
Connectivity technology	Wired
Ethernet LAN	No
Streaming method	Multicast
Supported network protocols	IPv4, ARP, TCP, UDP, ICMP, DHCP, NTP, DNS, DDNS, SMTP, FTP, HTTP, PPPoE, UPnP, RTP, RTSP, RTCP, HTTP, Bonjour
LED type	IR
Night vision distance	4.8 m
Minimum illumination	0 lx
Audio formats supported	ADPCM, PCM
Digital zoom	4 x
Fixed focal length	2.45 mm
Maximum aperture number	2.4
Compatible memory cards	MicroSD (TransFlash)
Password protection type	User
Mobile operating systems supported	Android, iOS
DC output current	1.2 A
DC output voltage	5
Power source type	DC
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	20 - 85 %
Number of cameras	1
Pallet width	1100 mm
Pallet length	1200 mm
Pallet height (air)	1994 mm
Pallet gross weight (air)	369950 g
Quantity per pallet (air)	825 pc(s)
Shipping (inner) case width	218 mm
Shipping (inner) case height	169 mm
Shipping (inner) case length	338 mm
Shipping (inner) case weight	2130 g
Shipping (inner) case net weight	1070 g
Number of cartons per pallet (air)	165 pc(s)
Harmonized System (HS) code	85258900
Quantity per shipping (inner) case	5 pc(s)

Weight and Dimensions

Depth	65.9 mm
Width	92.1 mm
Height	90.7 mm
Weight	140 g
Package depth	135 mm
Package width	63 mm
Package height	200 mm
Package weight	392.6 g
