18
In the “Option TAB”, there is the Refresh Time function. This function helps
you to refresh the time for monitoring the device. Choose 15 secs, 30 secs, 1
min, 2 min, and 5 min to select the time for monitoring.
In the “Help TAB”, there is About function, it will show out the version of
the Web Management Utility.
Configuring the Switch
The Web Smart 48-Port 10/100/1000Mbps Gigabit Switch has a Web GUI
interface for smart switch configuration. The Switch can be configured
through the Web Browser. A network administrator can manage, control, and
monitor the Switch from the local LAN. This section indicates how to
configure the Switch to enable its smart functions including:
Port Setting (Speed/Disable and Flow Control)
Virtual LAN Group setting (VLAN)
Trunk
Port Mirroring
QoS
SNMP
Jumbo Frame
System Setting
Device status and Statistics
Login
Before you configure this device, note that when the Web Smart Switch is
configured through an Ethernet connection, make sure the manager PC is set
on same the IP network. For example, when the default network address of
the default IP address of the Web Smart Switch is 192.168.0.1, then the
manager PC should be set at 192.168.0.x (where x is a number between 2 and
254), and the default subnet mask is 255.255.255.0.
Open Internet Explorer 5.0 or above Web browser.
Enter the IP address http://192.168.0.1 (the factory-default IP address setting)
into the address location.
Figure 13.
