DIS-200G Series Gigabit Ethernet Switch CLI Reference Guide
56
MEL
Ring MEL value of ERP instance.
R-APS Channel
APS channel of ERP instance.
Protected VLANs
Service protected VLANs of ERP instance.
Profile
The profile associated with the ERP instance.
Guard timer
Time value for guard timer of the profile.
Hold-Off timer
Time value for hold-off timer of the profile.
WTR timer
Time value for WTR timer of the profile
Revertive / Non-Revertive
Ring instances is operated in revertively or non revertively in the
profile.
Instance State
Current ring node status of ERP instance. Deactivated / Init / Idle /
Protection.
Admin/Operational RPL
Current config/running config ring node role of ERPS instance.
(Owner /None)
Admin/Operational Port0/port1
Current config/running config ring port role. (Interface_id /none)
Admin/Operational RPL Port
Current config/running RPL. (port0/port1 /none)
Ring port0/port1 state
State for ring ports of ERP instance. ( - / Forwarding / Blocked l)
Profile
The profile associated with the ring instances.
Inst ID
Instance identifier of ERP instance.
RingType
Indicates either major ring or sub ring.
Node Type
RPL Owner.
Status
Current status of ERP instance. It can be one of the following
values:
Deactivated: The ERP instance is deactivated.
Init: The instance is initializing.
Idle: The instance is in normal state. The RPL port is blocked.
Protection: The instance detects failure at some ring port. The RPL
port is restored to protect the port.
