D-Link DPR-1020 User Manual

External Features
D-Link DPR-1020 User Manual 6
External Features
Port Connectors
The DPR-1020’s USB printer port is located on the rear panel of the device and is
configurable using the web configurator.
The default IP address of the DPR-1020 is automatically acquired from a DHCP
server on the network. If a DHCP server cannot be found the default IP address for
the DPR-1020 will be 192.168.0.10.
NOTE: Your PC’s IP Address must be in the same subnet as the Print Server’s IP
Address for the two devices to communicate. (For example, if MFP server’s IP
Address is 192.168.0.10, with a subnet mask of 255.255.255.0, then your
computer’s IP Address should be 192.168.0.x, where x is a value between 1-254,
excluding 10.)

D-Link DPR-1020 Specifications

General

Networking standards	IEEE 802.3, IEEE 802.3u
Network connection type	Ethernet LAN
Dimensions (WxDxH)	67 x 106 x 25 mm
Power requirements	5.0V DC/2.5A
Compatible operating systems	Windows Vista/XP/2000/NT4/ME/98SE/95 Apple Mac OS 9.x - MAC OS X 10.4.x Linux UNIX lpr/lpd (HP-UX, SunOS, Solaris, SCO, UnixWare, IBM AIX) NetWare 5.x
DC-in jack	Yes
USB 2.0 ports quantity	1
Storage temperature (T-T)	-25 - 55 °C
Operating temperature (T-T)	0 - 40 °C
Certification	FCC Class B, CE, C-Tick, IC, CSA
Package depth	225 mm
Package width	150 mm
Package height	75 mm
Package weight	520 g

Weight and Dimensions

Depth	106 mm
Width	67 mm
Height	25 mm
Weight	77 g
