D-Link DSL-2750E User Manual

DSL-2750E User Manual
14
Field
Description
Protocol
Selected the protocol you subscribed from your ISP. It
displays the protocol type used for this WAN connection.
Encapsulation
Mode
Select the method of encapsulation provided by your ISP.
You can select
LLC
or
VCMUX
.
802.1Q VLAN
ID
You can enable or disable this function. The value ranges
from 1 to 4094. Value 0 means to disable this function.
- PPPoE or PPPoA
If the protocol is selected to be PPP over Ethernet (PPPoE) or PPP over ATM
(PPPoA), the following page appears.

D-Link DSL-2750E Specifications

ADSL Standards

G.dmt full rate downstream	up to 8 Mbps
G.dmt full rate upstream	up to 1 Mbps
G.lite ADSL downstream	up to 1.5 Mbps
G.lite ADSL upstream	up to 512 Kbps
G.dmt.bis full rate downstream	up to 12 Mbps
G.dmt.bis full rate upstream	up to 12 Mbps
ADSL full rate downstream	up to 24 Mbps
ADSL full rate upstream	up to 1 Mbps

Media Interface

ADSL interface	RJ-11 connector for connection to 24/26 AWG twisted pair telephone line
LAN interface	RJ-45 port for 10/100BASE-T Ethernet connection
